Volkswagen ID.3: Preparing Your Vehicle

Checklist

Always perform the following steps in the specified order to prepare for a wheel change→ :

1. Park the Volkswagen ID.3 vehicle a safe distance from moving traffic. Observe all important information on parking when doing so (→ Parking) . The ground must be level and firm. Sloped or soft ground can cause the vehicle to slip off the jack. If necessary, place a large, stable surface under the vehicle jack.

2. Switch on the emergency flashers (→ Center console) .

3. Have all vehicle occupants exit the vehicle on the side facing away from traffic and move to a safe area, such as behind a guard rail. Follow the local regulations regarding wearing a reflective vest.

4. Set up the warning triangle to warn others on the road about the vehicle.

5. Adjust the steering wheel so that the wheels are not pointing straight forward.

6. Block the tire that is diagonal from the one you will be changing with a stone, chocks, or another suitable object.

7. If the luggage compartment is full: remove the contents from the luggage compartment.

8. Remove the Volkswagen ID.3 vehicle toolkit from the luggage compartment.

WARNING

Failing to heed this checklist that is provided for your own safety can cause accidents and serious injuries.

• Always follow the tasks in the checklist.

• Observe the general safety precautions.

• Removing and Fitting Wheel Hub Covers
• Removing and Fitting the Wheel Bolt Caps
• Loosening wheel bolts
• Raising the vehicle with the vehicle jack
• Changing a wheel
• Sealing and pumping up tires
• Tire labeling and tire classifications

Removing and Fitting Wheel Hub Covers

Removing wheel hub covers

Fig. 1 Remove the wheel hub cover.

The full wheel covers protect the wheel bolts and must be reattached after a wheel change.

1. Take the extraction hook out of the Volkswagen ID.3 vehicle tool kit (→ Vehicle tool kit) .

2. Engage the extraction hook in one of the openings on the wheel hub cover.

3. Remove the wheel hub cover with extraction hook in the direction of the arrow. If necessary, use a lug wrench for removal → fig. 1 .

Installing the full wheel cover

1. Make sure the anti-theft wheel bolts are positioned correctly (→ Wheels and tires) .

2. Press the full wheel cover onto the rim so that the opening for the valve aligns with the tire valve. Make sure that the entire outer edge of the cover is secured.

WARNING

Unsuitable wheel covers and assembling wheel covers incorrectly can cause accidents and serious injuries.

Wheel covers that are installed incorrectly can loosen while driving and endanger other road users.

• Do not use damaged hubcaps.

• Check whether the wheel hub cover is securely engaged all the way around.

WARNING

Hubcaps that are installed incorrectly can cause the air supply for cooling the brakes to be interrupted or reduced.

This also applies when wheel covers are retrofitted. An insufficient air supply can cause the braking distance to increase significantly.

This can cause accidents and fatal injuries.

• Check whether the cut-out for the tire valve in the wheel hub cover is in the right position.

• Check whether the wheel hub cover is securely engaged all the way around.

NOTICE

The wheel hub cover might be screwed on tightly and may be damaged if it is pulled off.

• Do not use force to remove tightly screwed wheel hub covers.

Removing and Fitting the Wheel Bolt Caps

Removing the Caps

Fig. 1 Remove the caps from the wheel bolts.

The caps are for protecting the wheel bolts and must be completely reattached after a wheel change.

1. Take the extraction hook out of the Volkswagen ID.3 vehicle tool kit (→ Vehicle tool kit) .

2. Insert the extraction hook into the opening in the cap.

3. Remove the cap with extraction hook in the direction of the arrow→ fig. 1 .

Putting on Caps

1. Push the cap all the way onto the wheel bolts.

The anti-theft wheel bolt has a separate cap. This cap only fits on the anti-theft wheel bolt and not on conventional wheel bolts.

Loosening wheel bolts

Fig. 1 Loosening wheel bolts.

Use a suitable lug wrench to loosen the wheel bolts.

Only loosen the wheel bolts a few turns while the Volkswagen ID.3 vehicle is not raised with the vehicle jack.

1. Slide the lug wrench all the way onto the wheel bolt.

2. Hold the end of the lug wrench and turn the wheel bolt about one turn counterclockwise→ .

If a wheel bolt cannot be loosened, carefully press on the end of the lug wrench using your foot. Hold onto the vehicle firmly while doing this and make sure you have secure footing.

Loosening anti-theft wheel bolts

1. Remove the adapter for anti-theft wheel bolts from the Volkswagen ID.3 vehicle tool kit.

2. Slide the adapter all the way onto the anti-theft wheel bolt.

3. Slide the lug wrench all the way onto the adapter.

4. Hold the end of the lug wrench and turn the wheel bolt about one turn counterclockwise→ .

If a wheel bolt cannot be loosened, carefully press on the end of the lug wrench using your foot. Hold onto the vehicle firmly while doing this and make sure you have secure footing.

WARNING

If the wheel bolts are removed or loosened by more than one rotation before the Volkswagen ID.3 vehicle is jacked up, the wheel could fall off and the vehicle might tip.

This can result in serious injuries.

• Only loosen the wheel bolts about one turn while the vehicle is not lifted with the jack.

• Never place any part of your body, such as your arm, under the vehicle while you loosen the wheel bolts.

Raising the vehicle with the vehicle jack

Lift points

Fig. 1 On the side sill: markings for the jack lift points.

The Volkswagen ID.3 vehicle jack must only be positioned at the reinforced areas on the underbody that are located behind the markings on the vehicle body → fig. 1 . Always use the lift point that is nearest to the wheel you are changing→ .

Positioning the vehicle jack

Fig. 2 Correct jack setup.

Fig. 3 On the left side of the vehicle at the rear: jack in position.

Checklist

For your own safety, follow the points below in the order they are given→ :

1. Position the hand crank in the mount on the jack.

2. Find the Volkswagen ID.3 vehicle lift point → fig. 1 under the vehicle that is closest to the wheel you will be changing.

3. Crank the jack upward so that it is still positioned under the vehicle lift point.

4. Make sure the entire base of the jack is seated securely on the ground and that the base of the jack is located exactly directly below the lift point → fig. 2 and → fig. 3 .

5. Straighten the jack and continue cranking the claw on the top of the jack upward until the claw is positioned on the jacking point under the vehicle → fig. 3 .

6. Continue raising the vehicle jack until the wheel is lifted off the ground.

WARNING

Failing to heed this checklist that is provided for your own safety can cause accidents and serious injuries.

• Always follow the tasks in the checklist.

• Observe the general safety precautions.

WARNING

Using the Volkswagen ID.3 vehicle jack incorrectly can cause the vehicle to slip from the jack, resulting in serious injuries or death.

• Never raise the vehicle if more than one tire is damaged.

• Only place the vehicle jack at the lift points described. The bracket on the vehicle jack must firmly grip the sill → fig. 3 .

• Only use jacks that are approved by Volkswagen for the vehicle. Other vehicle jacks, including those approved for other Volkswagen models, could slip.

• Only jack up the vehicle on level, firm ground. Sloped or soft ground can cause the vehicle to slip off the jack. If necessary, place a large, stable surface under the jack.

• If you are on a slippery surface such as tile, place a non-slippery object such as a rubber mat on the ground to prevent the jack from slipping.

• Never place any part of your body, such as your arm, under the Volkswagen ID.3 vehicle when it is supported only by the jack. If you must work underneath the vehicle, additionally support the vehicle securely with suitable stands.

Changing a wheel

Removing a wheel

Fig. 1 Removing wheel bolts with the lug wrench.

1. Follow the checklist (→ Wheel change) .

2. Loosen the wheel bolts (→ Wheel bolts) .

3. Raise the Volkswagen ID.3 vehicle (→ Vehicle jack) .

4. Remove loose wheel bolts completely using the lug wrench → fig. 1 and place the bolts on a clean surface.

5. Remove the wheel.

Two-piece wheel bolts

Two-piece wheel bolts must be used. Two-piece wheel bolts have the bolt connected loosely to the head.

Do not use single piece wheel bolts. If you are not sure which wheel bolts to use for your Volkswagen ID.3 vehicle, consult an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

Installing a spare wheel or compact spare wheel

Fig. 2 Make sure the anti-theft wheel bolts are positioned correctly.

1. Note the running direction of the tire (→ Tire labeling and tire classifications) .

2. Position the wheel.

3. Install the anti-theft wheel bolt clockwise using the adapter in the correct position and lightly tighten.

On wheels with full wheel covers, the anti-theft wheel bolt must be fitted in position→ fig. 2 (2) or (3) , based on the position of the tire valve (1) . Otherwise, it will not be possible to install the full wheel cover.

4. Screw in the other wheel bolts clockwise, tightening them slightly.

5. Lower the Volkswagen ID.3 vehicle with the vehicle jack.

6. Tighten all wheel bolts securely clockwise using the lug wrench→ . Do not go in order around the wheel while doing this, but rather always switch to a wheel bolt on the opposite side.

7. Fit the caps or hubcap (→ Wheel covers) (→ Wheel bolt caps) .

After a wheel change

1. Clean the Volkswagen ID.3 vehicle tool kit and place it back in the foam piece in the luggage compartment.

2. Stow the old wheel securely in the luggage compartment.

3. Get the tightening torque of the wheel bolts checked as soon as possible at the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility. Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

4. Get the damaged tires replaced as soon as possible.

Introduction

Wheel bolt tightening specification

Tightening specification for wheel bolts in steel and aluminum alloy rims:

• 120 Nm (88 ft-lbs).

Wheel bolts that are corroded and difficult to turn must be replaced and the threads in the wheel hub must be cleaned before checking the tightening torque.

Never grease or oil the wheel bolts and the threads in the wheel hub.

Check the tightening torque using a functioning torque wrench immediately after changing a wheel.

WARNING

If the wheel bolts are not tightened enough to meet the specification, the wheel bolts and consequently the wheel could come loose while driving. Exceeding the tightening specification could damage the wheel bolts and threads.

Wheel bolts that are tightened incorrectly or missing could cause you to lose control of the Volkswagen ID.3 vehicle and lead to serious accidents and fatal injuries.

• Always tighten the wheel bolts to the correct tightening torque. If you do not have a torque wrench, tighten the wheel bolts with the lug wrench and then have the tightening torque checked as soon as possible by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

• Never drive with missing or loose wheel bolts.

• Always use wheel bolts that are correct for the rim and the Volkswagen ID.3 vehicle model.

• Never grease or oil the wheel bolts and the threads in the wheel hub. Even when tightened to the specification, they could become loose while driving.

• Ensure the wheel bolts and threads in the wheel hubs are clean, easy to move and free of oil and grease.

• Never loosen the bolts on rims with a bolted rim ring.

WARNING

Incorrect wheel bolts can loosen while driving and cause loss of vehicle control, serious accidents, and fatal injuries.

• Always use wheel bolts that are correct for the rim and the Volkswagen ID.3 vehicle model.

• Never use different wheel bolts.

• Use only two-piece wheel bolts on vehicles with two-piece wheel bolts.

The Tire Pressure Monitoring System (TPMS) indicator light may indicate a system malfunction after a wheel is changed (→ Tire Pressure Monitoring System) .

The tire mobility set allows you to temporarily and reliably seal tire damage caused by foreign bodies or punctures of up to around 4 mm in diameter. Do not remove the foreign body, such as a screw, from the tire! After the sealant has filled the tire, check and adjust the tire pressure again after a drive of approximately 10 minutes.

If more than one vehicle tired is damaged, seek advice from an authorized Volkswagen dealer or authorized Volkswagen Service Facility. The tire mobility set is only designed to fill one tire.

Only use the tire mobility set when the Volkswagen ID.3 vehicle is safely parked and you are confident of the necessaries skills and safety precautions! Otherwise, contact an authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance.

Do not use the tire sealant:

• When the wheel rim is damaged.

• In outside temperatures of below -20 ºC (-4 ºF).

• When cuts or punctures to the tire are larger than 4 mm.

• If you have driven with a very low tire pressure or an empty tire.

• If the tire filler bottle is past its use-by date.

• If a foreign body has been removed from the tire.

• In combination with an AirStop tire. You can tell if your Volkswagen ID.3 vehicle is equipped with AirStop tires by the lettering "Seal" on the outside of the tire.

WARNING

It can be dangerous to use the tire mobility set at the roadside.

If the vehicle and work area are not secured properly, serious accidents and fatal injuries may occur.

• Only use the tire mobility set yourself if you are familiar with the necessary steps. Instead, seek assistance from an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

• Stop the Volkswagen ID.3 vehicle as soon as it is safe to do so.

• Park the vehicle a safe distance from moving traffic (→ In case of an emergency) (→ Parking) .

• Make sure the vehicle is on level and solid ground.

• All passengers, especially children, must keep a safe distance and be clear of the work area.

• Switch on the emergency flashers to warn other road users and set up the warning triangle.

• When using the tire mobility set, never raise the Volkswagen ID.3 vehicle using a jack, even if the jack is approved for the vehicle.

WARNING

A tire filled with sealant does not have the same driving characteristics as an undamaged tire.

Over-stressing a sealed tire may result in serious accidents and fatal injuries.

• Never drive faster than 80 km/h (50 mph).

• Avoid hard acceleration, hard braking, and driving fast around curves.

• Drive at a maximum of 80 km/h (50 mph) for no more than 10 minutes and then check the tire.

•  Tires sealed with the tire mobility set should be replaced immediately. The tire mobility set is only intended for emergency use in order to reach the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility. Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

CAUTION

The sealing agent can be harmful if it comes into contact with your skin.

• If the sealing agent comes into contact with your skin, clean it off immediately with a cloth or other suitable item.

• Store the tire mobility set out of the reach of children.

Dispose of used or out-of-date sealant in accordance with statutory requirements.

Your authorized Volkswagen dealer or authorized Volkswagen Service Facility can provide you with a new tire inflation bottle. Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

Read the separate operating instructions provided by the tire mobility set manufacturer.

Preparing Your Volkswagen ID.3 Vehicle

Checklist

Always carry out the following tasks in the specified order→ .

1. Park your Volkswagen ID.3 vehicle a safe distance from traffic and on level and firm ground. Observe all important information on parking when doing so (→ Parking) .

2. Switch on the emergency flashers (→ Center console) .

3. Have all vehicle occupants exit the vehicle on the side facing away from traffic and move to a safe area, such as behind a guard rail. Follow the local regulations regarding wearing a reflective vest.

4. Set up the warning triangle to warn others on the road about the vehicle.

5. Check whether a repair with the tire mobility set is possible (→ Tire mobility set) .

6. If the luggage compartment is full: remove the contents from the luggage compartment.

7. Remove the tire mobility set from the luggage compartment.

8. Do not remove the foreign body, e.g. screw, from the tire.

WARNING

Failing to heed this checklist that is provided for your own safety can cause accidents and serious injuries.

• Always follow the tasks in the checklist.

• Observe the general safety precautions.

Sealing and pumping up tires

The tire mobility set is located in the luggage compartment under the luggage compartment floor.

Sealing tires

Fig. 1 Components of the tire mobility set (general example).

1. Label with the speed specification "max. 80 km/h" or "max. 50 mph".

2. Tire inflation hose with plug

3. Tire filler bottle

4. Replacement valve insert

5. Valve insert tool

The valve insert tool → fig. 1 (5) has a slot on the bottom end where the valve insert will fit. Only in this way can the valve insert be removed from the tire valve and reinstalled. This also applies to the replacement valve insert (4) .

1. Stick the label from the tire mobility set → fig. 1 (1) in the field of vision of the driver on the instrument panel.

2. Unscrew the valve cap from the tire valve.

3. Use the valve insert remover → fig. 1 5 to remove the valve insert from the tire valve and place it on a clean surface.

4. Shake the tire inflation bottle → fig. 1 3 vigorously back and forth a few times.

5. Attach the tire inflation hose → fig. 1 2 to the tire inflation bottle by screwing it on firmly in a clockwise direction. This automatically tears the film on the seal.

6. Remove the sealing plug from the tire inflation hose→ fig. 1 (2) and insert the open end fully onto the tire valve.

7. Hold the bottle with the base pointing upward and fill all the sealing agent from the tire inflation bottle into the tire.

8. Remove the empty tire inflation bottle from the valve.

9. Use the valve insert remover to screw the valve insert→ fig. 1 (5) back into the tire valve.

Pumping up tires

Fig. 2 Compressor in the tire mobility set (general example).

1. 12 V cable connector

2. ON and OFF switch

3. Tire pressure gauge

4. Air drain plug

5. Tire inflation hose

6. Compressor.

Instead of the air drain plug, there may also be a button on the compressor.

The compressor from the tire mobility set may be operated at the 12 V socket, even if the power specification on the compressor label exceeds the maximum power draw of the socket.

1. Screw the tire filler hose → fig. 2 (5) of the compressor firmly onto the tire valve.

2. Ensure that the air drain plug → fig. 2 (4) is turned off.

3. Activate the Volkswagen ID.3 vehicle's drive system.

4. Insert the 12-volt plug → fig. 2 (1) into a 12-volt-socket in the vehicle (→ Sockets) .

5. Switch the compressor on with the ON and OFF switch→ fig. 2 (2) .

6. Leave the compressor running until 2.0 - 2.5 bar (29 - 36 psi/200 - 250 kPa) is reached. Maximum run time: 8 minutes → .

7. Switch off the compressor.

If an air pressure of 2.0 - 2.5 bar (29 - 36 psi/200 - 250 kPa) cannot be reached:

1. Unscrew the tire inflation hose from the tire valve.

2. Drive the Volkswagen ID.3 vehicle around 10 meters (approx. 33 ft) forward or backward so that the sealing agent is distributed in the tire.

3. Firmly screw the tire filler hose of the compressor back onto the tire valve and repeat the inflation process.

4. If the required tire pressure still cannot be achieved, the tire is too badly damaged. The tire cannot be sealed with the tire mobility set. Do not continue driving → . Contact an authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance.

Continuing Your Journey

1. Disconnect the compressor and unscrew the tire inflation hose from the tire valve.

2. Immediately drive at a maximum of 80 km/h (50 mph), if a tire pressure of 2.0 - 2.5 bar (29 - 36 psi/200 - 250 kPa) has been reached.

3. After driving for ten minutes, check the tire pressure.

Check after 10 minutes of driving

1. Park the Volkswagen ID.3 vehicle on level and solid ground at the next safe opportunity, in a parking lot for example.

2. Reconnect the tire filler hose → fig. 1 (5) and read the tire pressure off the tire pressure gage → fig. 1 (3) .

1.3 bar (19 psi/130 kPa) and less:

Do not continue driving! The tire cannot be adequately sealed with the tire mobility set→ . Contact an authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance.

20 psi/140 kPa (1.4 bar) and above:

1. Readjust the tire pressure to the correct value.

2. Carefully drive to the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility at a maximum of 80 km/h (50 mph). Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

3. Have the damaged tire replaced at an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

   Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility.

WARNING

The tire inflation hose and the compressor may become hot during pumping and can cause burns if touched.

• Protect your hands and skin from hot parts.

• Do not place the hot tire inflation hose or compressor onto flammable materials.

• Allow the tire inflation hose and compressor to cool before you put them away.

WARNING

If the damaged tire cannot be adequately sealed with the tire mobility set, the tire will lose air while driving.

This could cause tire failure, loss of Volkswagen ID.3 vehicle control, accidents, and serious injuries and death.

• If the tire cannot be pumped to at least 2.0 bar (29 psi/200 kPa), the damage is too great. The sealing agent cannot seal the tire. Do not continue driving and instead seek professional assistance.

• Do not continue driving if the tire pressure is 1.3 bar( 19 psi/130 kPa) or less after 10 minutes of driving. Instead, seek professional assistance.

NOTICE

The compressor can overheat and become damaged if it is used for too long.

• Switch the compressor off after it has been running for eight minutes at the most.

• Allow the compressor to cool down for a few minutes before switching it on again.

Tire labeling and tire classifications

Fig. 1 International tire labeling.

→ fig. 1 Tire labeling (example), meaning

1. Product name

Individual manufacturer tire designation.

2. DOT

The tire conforms to the legal requirements of the Department of Transportation in the USA, which is responsible for tire safety standards.

3. JHCO CHWS 2213

Tire Identification Number (TIN - may only be on the inner side of the tire) and production date:

JHCO CHWS- Code for the factory that produced the tire and specifications from the tire manufacturer for the tire size and tire characteristics.

2213- Production date: 22nd week in the year 2013.

Information for the end consumer about comparative values for specified base tires( standardized test procedures) :

4. TREADWEAR 280

Relative service life expectancy for the tire, based on a US-specific standard test. A tire with the specification 280 will wear 2.8 times more slowly than a standard tire with a tread wear value of 100. The tire performance depends on the usage conditions and may differ significantly from the standard values depending on the driving behavior, maintenance, different road conditions, and climate conditions.

5. TRACTION AA

Wet braking capability of the tire (AA, A, B or C). The wet braking capability is measured under controlled conditions on certified test courses. Tires marked with C have low traction performance. The traction value assigned to tires is based on straight-line traction test and includes neither acceleration and cornering, nor hydroplaning and traction under maximum load.

6. TEMPERATURE A

Temperature stability of the tire at high speeds on the test stand (A, B or C). Tires marked with A and B exceed the legal requirements. The temperature rating is based on the tires being inflated to the correct pressure and not overinflated. Excess speed, incorrect tire pressure, and overinflation either alone or in combination can cause heat to build up and cause tire damage.

7. 88 H

Load index → Tire load and speed rating → Speed rating .

Rotation and arrow

• Tire running direction code → Unidirectional tires .

Or: Outside

• Code on the outside of the tire → Asymmetrical tires .

9. MAX INFLATION 350 KPA (51 psi/3.51 bar)

US limit for the maximum inflation pressure.

10. M+S or M/S or

Code for tires that can be used in the winter (mud and snow tires) (→ Winter tires) .

Studded tires are marked with an E after the S.

11. TWI

Indicates the location of the tread wear indicator (→ Tread depth and wear indicator) .

12. Brand name, logo

Manufacturer.

13.

Symbol for Volkswagen Genuine tires .

14. Made in Germany

Country of manufacture.

15.

Country-specific code for China (China Compulsory Certification).

16. 023

Country-specific code for Brazil.

17. E4 e4 0200477-b

Identification according to international regulations with the number of the country that issued the approval. Approved tires in accordance with ECE regulations are marked with an E. Tires in accordance with EU regulations are marked with ane . The multi-digit approval number follows that.

18. RADIAL TUBELESS

Tubeless radial tires.

Size designation:

P- Code for passenger vehicles.

19. P 195 / 65 R 15 XL

195- Tire width from one sidewall to the other in mm.

65 -Height and width ratio in %.

R- Belt construction code for radial.

15- Rim diameter in inches.

XL- Reinforced tires ("Extra Load").

20. MAX LOAD 615 KG (1235 LBS)

US load capacity for the maximum load per tire.

21. SIDEWALL 1 PLY RAYON

• Specification for the components of the tire body.

  1 layer rayon.

21. TREAD 4 PLIES

Specification for the components of the running surface.

1 RAYON + 2 STEEL + 1 NYLON

• In the example, there are the following 4 layers under the running surface: 1 rayon layer, 2 steel belts, and 1 nylon layer.

The labeling is on both sides of the tire. In some cases, certain codes may only be on one side of the tire, such as the tire ID number and the production date.

Other digits that may be present are part of the internal labeling from the tire manufacturer or country-specific labeling.

Low-profile tires

Compared to other tire-rim combinations, low-profile tires offer a wider tread surface and a larger rim diameter with shorter tire sidewalls. Low-profile tires improve handling performance and precision. However, they may reduce the level of comfort when driving on roads in poor condition.

Unidirectional tires

The sidewalls on unidirectional tires are marked with arrows. The specified running direction must be followed. This ensures the optimum running characteristics.

If a tire is mounted opposite from the specified running direction, drive more carefully because the tire is not being used the way it was designed to be used. The tire must be replaced or mounted in the correct running direction as soon as possible.

Asymmetrical tires

Asymmetrical tires factor in the behavior of the inner and outer areas of the tread pattern. The sidewalls on asymmetrical tires are marked as the inner and outer side. Maintain the correct position of the tire on the rim.

Tire load

The tire load index indicates the maximum load of an individual tires in kilograms.

Some examples:

78

425 kg (936 lbs)

81

462 kg (1018 lbs)

83

487 kg (1073 lbs)

85

515 kg (1135 lbs)

87

545 kg (1201 lbs)

88

560 kg (1234 lbs)

91

615 kg (1355 lbs)

92

630 kg (1388 lbs)

93

650 kg (1433 lbs)

95

690 kg (1521 lbs)

97

730 kg (1609 lbs)

99

775 kg (1708 lbs)

100

800 kg (1763 lbs)

101

825 kg (1818 lbs)

102

850 kg (1873 lbs)

103

875 kg (1929 lbs)

104

900 kg (1984 lbs)

Speed rating

The speed rating indicates the maximum speed that may be driven with the tire.

P

max. 150 km/h (93 mph)

Q

max. 160 km/h (99 mph)

R

max. 170 km/h (106 mph)

S

max. 180 km/h (112 mph)

T

max. 190 km/h (118 mph)

U

max. 200 km/h (125 mph)

H

max. 210 km/h (130 mph)

V

max. 240 km/h (149 mph)

W

max. 270 km/h (168 mph)

Y

max. 300 km/h (186 mph)

Z

above 240 km/h (149 mph), depending on manufacturer also ZR.

Tire load and speed range

Vehicles within the EU and EU member states receive a Certificate of Conformity( COC). The COC contains specifications about the size and diameter as well as load capability and speed range of the tires approved by Volkswagen for the applicable vehicle model.

The model plate will indicate if the Volkswagen ID.3 vehicle has a COC .

• If the model plate contains a line labeled "Authorization", then the vehicle has a COC.

• If there is no model plate or the "Authorization" line is not included, then the Volkswagen ID.3 vehicle does not have a COC.
